Douk Audio T3 Plus: Tube MM/MC phono stage with headphone output

Douk Audio T3 Plus can be used as MM/MC phono stage, tube audio preamp and headphone amplifier, powerful features in mini size, specially designed for different requirements.

Features of Douk Audio T3 Plus

• Multiple audio inputs for different purposes: with 3.5mm AUX and phono inputs, supports MM and MC cartridges, well compatible with various MM/MC players and other audio devices to meet different requirements.
• With headphone output and perfect design: Can be used as a headphone amplifier to drive 32-300 ohm headphones. Reasonable and advanced circuitry and high-quality components such as 3PCS JRC2608 power operational amplifiers, high-end power management part, etc.
• Plug-in vacuum tube design and HiFi sound: using 6A2 tubes to soften, the sounds are warm and gentle, full and soft, much softer and more listenable. Can be directly replaced with 6J1/6J4/GE5654/6AK5/6X1N to enjoy different sound styles.
• Unique appearance and correct size: Vertical placement design, black solid aluminum body with wire pattern and matte technology, looks cool and distinctive, both aural and visual pleasure, very suitable for audiophiles who pursue HiFi sound.

3.5mm AUX input with priority, please make sure the AUX cable has been pulled out if want to use the phono input.
Stereo RCA and 3.5mm headphone jack can work simultaneously.



Characteristics of Douk Audio T3 Plus:

• Audio input: phono/turntable (RCA) / 3.5mm AUX
• Audio Output: Stereo RCA/3.5mm headphone jack
• AUX INPUT
  • AUX input level: 1V
  • Maximum RCA output level: 2V
  • Frequency response: -1dB (20Hz-20KHZ)
  • THD: 0.01%
  • SNR: 100 dB
• PHONO INPUT
  • Phono Input Level: 0.005V
  • Maximum RCA output level: 530 mV (MM) / 5 V (MC)
  • Frequency Response: Meets RIAA specifications
  • THD: 0.2%
  • SNR: 89 dB
• Headphone output power: 130mW@32Ω
• Headphone matched impedance: 32-300Ω
• Operating voltage: DC 12V
• Dimensions (WXLXD): 50X120X138 mm
• Package dimensions (WXLXD): 320X240X80 mm
• Net weight: 540g
• Package weight: 900 g
