Onkyo CR N775D: Powerful and easy to use network cd reciever

The Onkyo CR-N775D plays any music you can imagine, along with the easiest-to-use interface, with the same energy and fluidity as a full-blown hi-fi component. Using patented 3-State Bitstream™ switching amplification circuitry, this receiver packs plenty of power and delivers precision, high-resolution audio with vanishingly low distortion, ideal for Hi-Res recordings. The music he performs sounds on a wide stage, and the high speed of transient processes allows him to handle the most complex musical passages with confidence and refinement.

When playing music, the Onkyo CR-N775D delivers a wide soundstage, and its high transient speed allows it to handle complex musical passages with confidence and finesse. The Onkyo CR-N775D supports multi-room audio distribution via built-in Chromecast, DTS Play-Fi® and FlareConnect™ platforms, and is ready to stream music from virtually any mobile device or PC. It also features AirPlay, Bluetooth® and dual-band Wi-Fi® (5 GHz/2.4 GHz), as well as support for Spotify® applications.

You can connect a HDD drive to the CR-N775D's USB input and use it to store and play files downloaded to a PC, including Hi-Res Audio in MQA format (firmware update required), Direct DSD 11.2 MHz and 192 kHz/24-bit FLAC, WAV and ALAC. Music from services such as TIDAL, Deezer and TuneIn, along with FM/DAB+ radio broadcasts, as well as audio from digital and analogue sources, can be easily selected using the JOG knob and large LCD display.

Blackfire's FireConnect™ is a wireless protocol that is fundamental to ONKYO's Next Generation Network Audio concept. The NGNA concept operates on dual-band 5GHz/2.4GHz Wi-Fi via the ONKYO Controller app for iPod touch, iPhone, iPad and Android™ devices to make music sharing simple and intuitive. The update allows you to stream from Internet services built into components including TIDAL, Deezer and TuneIn, as well as Spotify®, to stream audio from different sources connected to the same wireless network into FireConnect™-enabled speakers (ONKYO NCP-302). Sampling rates of 44.1 kHz and 48 kHz are supported.

The audio system has convenient control thanks to an informative LCD display and a convenient multifunctional Jog/Dial switch. The Onkyo CR-N775D is equipped with improved Class D amplifiers with extended frequency and dynamic ranges. In addition, Optimum Audio Control technology ensures precise matching of the amplifier with the included speakers, resulting in very rich and balanced sound. The system provides an output for connecting an active subwoofer if you need to provide sound in a large room.

The device is equipped with a sensitive tuner operating in the AM and FM bands, and has a memory for 20 station settings. Among the additional functions of the receiver are the presence of an on/off timer and an auto-shutdown mode. To connect speakers, the Onkyo CR-N775D has two pairs of reliable screw terminals (also suitable for connecting banana terminals). Onkyo recommends using Onkyo D-165 speakers in conjunction with this receiver, and then you can use the speaker-receiver matching optimization system to improve sound quality.

Specifications Onkyo CR-N775D

Power 40 W x 40 W (4 Ω, 1 kHz, 10% THD, 2 channels active, IEC)
Patented 3-state Bitstream™ hybrid pulse amplification technology, provides high pulse resolution, extremely low distortion and high output power
Capable of delivering high instantaneous currents, increased sound pressure and realistic sound field reproduction
Wide frequency range for authentic high-resolution audio reproduction High-
quality AKM AK4490 768 kHz/32-bit DAC for Hi-Res Audio playback
Supports Direct DSD 11.2 MHz and 192/24 Hi-Res Audio in FLAC, WAV and Apple Lossless formats via network and PC*1
Tone controls (Bass and Treble)
Pre Out to subwoofer
Full color on-screen display of album art, song titles, artists
Next generation network audio for multi-room distribution Dual
-band Wi-Fi (5 GHz/2.4 GHz) for a stable network connection
Built-in Chromecast technology for wireless audio streaming
FlareConnect wireless technology for multi-room network audio distribution to compatible components and speakers
DTS Play-Fi support for multi-room playback of
Plug-and- audio files Play playback from USB-HDD drives and USB flash drives via front USB input with easy navigation using Device Music Server, updating from a connected PC
Control and control of multi-room playback using the intuitive Onkyo Controller application for Android and iPhone/iPad
Supports Spotify, TIDAL services , TuneIn and Deezer
Audio streaming from mobile devices and PC via Bluetooth® (Version 4.1 +LE, A2DP/AVRCP) with Wake On Play, Bluetooth Standby and Auto Connect functions
FM/RDS and DAB+ tuners radio with memory for 40 stations
CD player Front-loading, compatible with Audio CD, CD-R, CD-RW and MP3-encoded CDs (320 VBR/CBR) 192 kHz
analog line in and out
/24-bit compatible coaxial and optical digital input
2 USB audio inputs (5 V / 0.5 A, front, 5 V / 1 A, rear)
LAN connector for Ethernet LAN
IR connector for component control
Pre Out for subwoofer
FM/DAB+ antenna connector
Gold-plated speaker terminals with clear screw terminals
3.5mm headphone
jack AC Inlet for power cord
Dimensions (W x H x D) ): 215 x 117 x 295 mm
Weight 2.7 kg
