SMSL H400: Powerful new preamp/headphone amplifier

SMSL H400 is a new preamp/headphone amplifier with high output power (up to 15W).

SMSL H400 Specifications:

• Inputs: balanced, unbalanced
• Headphone outputs: 4.4 mm balanced, XLR balanced, 6.35 mm RCA
• Preamp Outputs: Balanced, Unbalanced
• Output power:
  • 16Ω: 15W x 2
  • 32Ω: 7.5W x 2
  • 300Ω: 1000mW x 2
  • 600Ω: 550mW x 2
• Signal to Noise Ratio (SNR): 133dB
• Dynamic range: 133dB
• Harmonic distortion + noise (THD+N): -123dB, 0.00006% (1kHz, 32Ω)
• Input impedance: 47kΩ
• Headphone output impedance: close to 0Ω
• Preamp output impedance:
  • Balanced: 44Ω
  • Unbalanced: 22Ω
• Frequency range: 20Hz – 100kHz (-0.5dB)
• Gain:
  • Balanced: Low (-5.8dB), Mid (6dB), High (20.4dB)
  • Unbalanced: Low (-11.8dB), Mid (0dB), High (14.4dB)
• Power consumption (EN60065): <50W
• Standby consumption: <0.5W
• Dimensions: 254 x 46 x 189 mm (W x H x D)
• Weight: 2.03 kg

Price : $510
