Denon AVR-S760H: 7.2-channel AV receiver that can handle 8K resolution

The Denon AVR-S760H 7.2-channel AV receiver can handle 8K resolution and is equipped with seven discrete high-current amplifiers that deliver 140 W per channel into 6 ohms and can handle even 4 ohm speakers. The receiver supports major object-based 3D sound formats, including DTS:X and Dolby Atmos in 5.1.2-channel version. DTS Virtual:X and Dolby Atmos Height Virtualization Technology are available to simulate the sound of dedicated Atmos speakers or in-ceiling speakers in 5.2, 7.2 or 2.2 channel systems that are not equipped with such speakers.

The Denon AVR-S760H receiver is capable of playing audio files, incl. HD formats FLAC, WAV and ALAC up to 24-bit/192 kHz or DSD (2.8/5.6 MHz), which are stored on local network computers/NAS servers or external drives connected to front USB. A web connection provides access to various streaming services, including Spotify Connect, Tidal, TuneIn, Deezer, etc. The receiver supports dual-band Wi-Fi, Bluetooth and the AirPlay 2 protocol, which opens up possibilities for wireless multiroom installations based on Apple devices.

The Denon AVR-S760H feels confidently part of the HEOS ecosystem, which goes wireless and controls all HEOS devices through one app. You can transfer an audio stream from tablets/smartphones, online services and local networks to such devices directly from the application. You can play the same song in different rooms with perfect synchronization or specially selected tracks for each individual room.

The Denon AVR-S760H model supports “communication” with personal assistants Apple Siri, Amazon Alexa and Google Assistant, which open up the possibility of voice control of the receiver. You can also control it in the traditional way using a remote control or an application. To configure the receiver, use the intuitive Setup Assistant program. The Audyssey MultEQ system algorithm is used to auto-calibrate the speakers. Dynamic Volume and Dynamic EQ technologies are also used to optimize volume and frequency response.

The Denon AVR-S760H receiver has six HDMI inputs, three of which support 8K Ultra HD/60 Hz, HDCP 2.3 and HDR10, Dolby Vision and HLG video standards. There is an HDMI output with support for an extended eARC return channel, which allows you to transmit 3D audio (Dolby Atmos, etc.) to the receiver directly from the TV panel. Among other switching, one can highlight the presence of an MM phono stage input. To connect speaker systems, seven pairs of screw terminals, designated in different colors, are used.

Specifications Denon AVR-S760H

Output power 75 W per channel (8 ohms, 20 Hz – 20 kHz, THD: 0.08%, 2 channels active), 110 W per channel (6 ohms, 1 kHz, THD: 0.7% , 2 channels active), 140 W per channel (6 Ohms, 1 kHz, THD: 1%, 1 channel active)
Input sensitivity 200 mV (line input), 2.5 mV (MM phono stage)
Frequency range 10 Hz – 100 kHz (+ 1, – 3 dB, Direct mode, analog jacks)
Signal-to-noise ratio 98 dB (analog line-level jacks, Direct mode)
AM/FM tuner
Built-in decoders (main) DTS:X (up to 5.1.2), DTS Neural:X, DTS Virtual:X, DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS Digital Surround, DTS-ES, DTS 96/24, DTS Express, Dolby Atmos (up to 5.1.2), Dolby Atmos Stream , Dolby Atmos Height Virtualization Technology, Dolby Digital Plus, Dolby TrueHD, Dolby Surround
Direct mode
Supports HEOS wireless multiroom network
Supported audio formats (via LAN and USB) MP3, WMA, AAC, FLAC, FLAC HD (up to 24 bit/192 kHz ), ALAC (up to 24 bit/192 kHz), WAV (up to 24 bit/192 kHz), DSD (up to 5.6 MHz)
Compressed audio restoration supported
Gapless playback mode for FLAC, WAV, ALAC, DSD
Web -services TuneIn, Spotify Connect, Tidal, Deezer, Amazon Prime Music, etc.
Auto-calibration system for speakers Audyssey MultEQ
Technologies Audyssey Dynamic EQ/Dynamic Volume
Support for the Audyssey MultEQ Editor application for finer correction of speaker calibration settings
Support for Wi-Fi IEEE 802.11a/b /g/n, 2.4/5 GHz
Support Bluetooth version 4.1, maximum range: up to 30 m
AirPlay/AirPlay 2 support yes
Support 8K Ultra HD 4K (50/60 Hz, 4:4:4 Pure Color)
Pass-through signal via HDMI in standby mode
8K resolution pass-
through 3D video pass-through
Voice control supported using Amazon Alexa, Google Assistant, Apple Siri
Inputs 6 x HDMI (8K/60 Hz, HDCP 2.3, HDR10, Dolby Vision, HLG , BT.2020), 2 composite, 2 linear RCA, MM phono input (RCA), 2 optical, USB for external drives (on the front panel), LAN interface
HDMI outputs (8K/60 Hz, HDCP 2.3, ARC, eARC, CEC), composite, Pre Out for two active subwoofers (2 RCA connectors), 6.3 mm headphone jack
Other Connections 3.5mm calibration microphone input, AM/FM antenna jacks, 2 Wi-Fi/Bluetooth antenna jacks, ground terminal
Supports CEC control protocol for smart TV operation
Speaker terminals 7 pairs of color-coded screw terminals marked (4–16 Ohm)
Eco mode
Power consumption 430 W, standby: 0.1 W
Remote control RC-1227
Dimensions (WxHxD) 434x151x329 mm (without antennas), 434x151x339 mm (Wi-Fi/Bluetooth antennas in horizontal position ); 434x215x339 mm (Wi-Fi/Bluetooth antennas in vertical position)
Weight 8.6 kg
