Lyngdorf CS-2: Built-in full-range shelf speaker

The Danish brand Lyngdorf , part of SL Audio A/S , presented the Lyngdorf CS-2 built-in box speaker system at ISE 2023 in Barcelona . The novelty is intended primarily for embedding in furniture, but can also be mounted in a niche in the wall.

The Lyngdorf CS-2 complements the Lyngdorf CS-1 cabinet speaker introduced in October 2020 with less depth. The rugged MDF cabinet with a matte black finish is only 20cm deep, 10cm less than the Lyngdorf CS1. Thus, we can talk about the appearance in the Lyngdorf nomenclature of a whole series of cabinet acoustics CS.

The emitters here are the same as those used in the Lyngdorf CS-1 model. An inch tweeter with a soft fabric dome is responsible for the high-frequency range. The rest of the range is entrusted to a driver with an aluminum cone with a diameter of 6.5 inches and a 35 mm voice coil, which works in a phase-inverted design – the phase inverter port is displayed on the front panel.

The Lyngdorf CS-2 built- in cabinet speaker will be available in April 2023. The recommended retail price in Europe is 799 euros per speaker.

Technical characteristics of acoustic systems Lyngdorf CS-2:

• Type: built-in cabinet two-way speaker system
• Maximum input power: 100 W
• Drivers: 1″ tweeter, fabric soft dome, PTC protection, 6.5″ mid/bass driver, aluminum cone, 35 mm voice coil, molded basket, crossover frequency 2.2 kHz
• Acoustic design: bass-reflex port on the front panel
• Frequency response: 42Hz to 22kHz (-3dB)
• Rated impedance: 4 ohm
• Sensitivity: 88dB (2.83V/1m)
• Single speaker dimensions (W x H x D): 420 x 307 x 200 mm
• Single speaker weight: 8.1 kg
