Shanling SM1.3: Next-gen streamer equipped with cutting-edge technology

At its core, the Shanling SM1.3 utilizes a DAC powered by the AKM AK4499EX chip, complemented by the TPA6120 headphone amplifier.

The SM1.3 offers native compatibility with popular streaming services such as Spotify, TIDAL, Apple Music, Apple Classical, and Amazon Music. Additionally, it includes a USB input for external storage devices and an M.2 SSD slot, allowing for the expansion of digital music libraries and the creation of a DLNA-compatible music server.

The 5.8-inch touchscreen provides quick and responsive access to options, and all functionalities can be managed through the Eddict app available for both Android and iOS devices.

This device supports Wi-Fi 6, features built-in AirPlay 2, and includes an Ethernet port for straightforward network connectivity for users who prefer a wired connection.

Bluetooth 5.2 is included, offering support for both LDAC and aptX HD. The device features optical and coaxial inputs and outputs, while providing an analog signal through RCA and XLR connections.

Additionally, it is equipped with an I2S digital output utilizing FPGA technology (via HDMI), which ensures compatibility with ten different external DACs. A USB DAC is also available through the USB-C port.

As a headphone amplifier, it includes a 6.35mm output jack with various gain levels: Low Gain at 0.79mV@32Ω (19mW@32Ω), Medium Gain at 2.4V@32Ω (180mW@32Ω), High Gain at 5.7V@32Ω (1015mW@32Ω), and High Gain at 6.3V@300Ω (132mW@300Ω).

The Shanling SM1.3 represents a new generation of streamers, measuring 28x28x110 cm.

It will be available starting November 8, priced at €1199.

Additionally, the company plans to launch the Shanling S0 active speakers, which will retail for €399.

Technical Parameters

RCA Output:
Output Level: 2.36V
Frequency Response: 20Hz-40kHz (-0.5dB)
THD+N: 0.0003%
Dynamic Range: 118dB
Channel Separation: 117dB
Signal-to-Noise Ratio: 118dB

XLR Output:
Output Level: 4.72V
Frequency Response: 20Hz-40kHz (-0.5dB)
THD+N: 0.0003%
Dynamic Range: 121dB
Channel Separation: 117dB
Signal-to-Noise Ratio: 121dB



Headphone Output:
Output Power:
Low Gain: 19mW@32Ω
Medium Gain: 180mW@32Ω
High Gain: 1015mW@32Ω
High Gain: 132mW@300Ω
Frequency Response: 20Hz-40kHz (-0.5dB)
THD+N: 0.0013%@32Ω
Dynamic Range: 117dB@32Ω
Channel Separation: 70dB@32Ω
Signal-to-Noise Ratio: 117dB@32Ω
Noise: 111dB
Output Impedance: 4.7Ω

Digital Ports Specifications
Coaxial Input: PCM192kHz / 24bit
Optical Input: PCM192kHz / 24bit
USB Input: PCM768kHz / 32bit, DSD512

Coaxial Output: PCM192kHz / 24bit
Optical Output: PCM192kHz / 24bit
USB Output: PCM768kHz / 32bit, DSD512
I²S Output: PCM768kHz, DSD512
